| WUXI ORIGINAL MECHANICAL & ELECTRICAL Co.,Ltd |
 |
| Data Sheet / 数据表 |
No/数据表号 |
OMEC-1007 |
| Three Phase Induction Motor/三相感应电动机 |
Drawing No/外形图号 |
OST0-355F0-02P 3~7kV B3 |
| Type/ 产品型号 |
OST4-355F1-02P 220kW 6000V 50Hz |
| Identification |
| Frame / 机座 |
355 |
mm |
Insulation Class/绝缘等级 |
F |
| Output / 功率 |
220 |
kW |
Temperature Rise/ 温升 |
80K |
| Frequency / 频率 |
50 |
Hz |
Service Factor / 服务系数 |
1.0 |
| Poles / 极数 |
2 |
P |
Duty / 工作制 |
S1 |
| Rated Speed / 额定转速 |
2975 |
Rpm |
Ambient Temperature/ 环境温度 |
-20～40°C |
| Slip / 转差率 |
0.83 |
% |
Altitude / 海拨 |
1000m |
| Rated Voltage / 额定电压 |
6000 |
V |
Protection Degree / 防护等级 |
IP23 |
| Connection / 定子接法 |
Y |
|
Cooling / 冷却方式 |
IC01 |
| Rated Current / 额定电流 |
26.4 |
A |
Mounting / 安装方式 |
IM B3/B35/V1 |
| Rotor Voltage / 转子电压 |
- |
|
Vibration / 振动值 |
2.3 mm/s |
| Rotor Connection / 转子接法 |
- |
|
Approx. Weight / 重量 |
2000 kg |
| Rotor Current / 转子电流 |
- |
|
Moment of Inertia /转动惯量 |
3.536 kg-m2 |
| Locked Rotor Current 堵转转子电流 |
700 |
% |
Noise Level（Lp）/声压级 dB(A) |
93 |
| No Load Current / 空载电流 |
- |
|
Direction of Rotation/转向 |
BOTH |
| Rated Torque / 额定转矩 |
706.22 |
Nm |
Starting Method/起动方法 |
DIRECT ON LINE |
| Locked Rotor Torque / 堵转转矩 |
60 |
% |
Coupling / 联接方式 |
DIRECT |
| Breakdown Touque / 最大转矩 |
180 |
% |
Load Type/ 负载性质 |
- |
| Performance |
Bearing Information |
| Output / 输出 |
50% |
75% |
100% |
|
DE / 轴伸端 |
NDE / 非轴伸 |
| Efficiency(%)效率： |
90.5 |
93.5 |
93.3 |
Bearing / 轴承型号 |
6218C3 |
6218C3 |
| Regreasing int, / 润滑周期(h) |
2000 |
2000 |
| Power Factor功率因数 |
0.73 |
0.82 |
0.86 |
Grease amount / 润滑剂量(g) |
25 |
25 |
| Grease-PolyrexEM / 润滑剂 |
Chevron SRI-2 |
Chevron SRI-2 |
| Standards / 标准 |
Notes / Accessories / 注意点及附助元件 |
| Specification / 规范 |
IEC60034-1 / GB/T755 |
With winding RTD: PT100 6 PCS |
| Test / 试验 |
IEC60034-2 / GB/T1032 |
With Bearing RTD: PT100 2 PCS |
| Noise / 噪声 |
IEC60034-9 / GB/T10069.1 |
With Space Heater 230V 400W |
| Vibration / 振动 |
IEC60034-14 / GB/T10068 |
|
