NEMA TEFC 低压电机  OMN 145T-2  1.5kW  575V  T
数据表
表格可左右滑动查看
OMEC NORTH AMERICA INC
NEMA  Motor
　 Drawing No. TEFC 143 145T
Customer : 　
Client reference: 　
Type:  OMN 145T-2
Brand : OMEC
TYPICAL MOTOR PERFORMANCE DATA
HP kW Pole FL RPM Frame Voltage Hz Phase FL Amps
2 1.5 2 3490 145T 575 60 3 2.05
Enclosure IP Ins.Class S.F. Duty NEMA
Nom. Eff.		 NEMA
Design		 kVA Code Ambient
(℃）
TEFC 55 F 1.15 CONT 85.5 B L 40
　
Load HP kW Amperes Efficiency (%) Power Factor
Full Load 2 1.5 2.05 85.5 0.86
　 　 　 　 　 　
　 　 　 　 　 　
　 　 　 　 　 　
　 　 　 　 　
Locked Rotor 20 　
　
Torque Rotor wk2
Inertia
(ib-ft2)
Full Load
(Ib-ft)		 Locked Rotor
(% FLT)		 Break Down
(% FLT)
3.0 170 250 　
　
Safe Stall Time(s) Sound
Pressure
dB(A)@1M		 Bearings Approx. Motor Weight
(Ibs)
Cold Hot
DE NDE
　 　 　 6205 2Z 6203 2Z 　
*Bearings are the only Recommended spare part(s).
Motor Options:
　
　
　
　
　
Edition
Performed Checked Date
　 　 　
　
Item Changes Performed Checked Date
　 　 　 　 　
　 　 　 　 　
　 　 　 　 　
　 　 　 　 　
　 　 　 　 　
　 　 　 　 　
数据表
OMN 145T-2
145T
2
B
L
CONT
OMN 145T-2
3
F
TEFC
40
80℃
1000M
F1
55
411
60
575
2
2.05
1.5
3490
1.15
85.5
0.86
6205 2Z
6203 2Z
